1, whole shell stainless steel 304/316 l material dewaxing precision casting is made, specially chosen micro acid weak base of sewage wastewater.
2, cable base station and core are subject to special fault leakage waterproof processing, the single core using stripping packaging processing, effectively prevent moisture from cable joint or core infiltration motor, fully to leak, prevent damp sealing effect.
3, cone type pump shell flow and Vortex type Vortex impeller, the special non-clogging design, extraction sludge, dirt all can be twice the result with half the effort.
4, pump shell runner can add "getter bolt", in order to avoid "air cock" phenomenon, to ensure that smoke discharge the water piping system stability.
5, mechanical shaft seal parts carry high quality double group type mechanical shaft seal, and comprehensive configuration SIC carborundum mechanical shaft seal.
6, motor using insulation class F level (155 °C) of the dry induction motor, shell protection class for IECIP68.
7, full series motor configuration temperature controller or motor overload protector, effectively prevent motor anomaly overload when burned.
8, full range of optional collocation automatic coupling devices, by simple installation construction will water pipe fixed edge in the main body of the coupled device, seat, encounter pump must be maintenance, maintenance can be easily by the chain hoist by guide for lifting, from, joint production, engineering personnel need not into the tank dismantling, effectively improve the operation of the convenience of Ann by nature.
| Power Source | Electric |
| Pump Brand | readycome |
| Motor | 3 phase/50 Hz |
| Liquid | wastewater, sludge, dirty water, Clean Water |
| Application | Sewage |
| Material | 304/316 stainless steel |
