Single Stage Centrifugal Water Pump Vertical Inline Pump 220V-380V

Name: Single Stage Centrifugal Water Pump Vertical Inline Pump 220V380V
Brand: READYCOME
Price: 1 USD

Single Stage Centrifugal Water Pump Vertical Inline Pump 220V-380V Manufactures

MOQ : 10 sets

Price : CN¥1,081.28/sets 10-99 sets

Brand Name : READYCOME

Place of Origin : China

Payment Terms : L/C,D/A,T/T,D/P

application : Commercial Buildings

structure : Single-stage Pump

voltage : 220V-380V

Phase : 3Phase

Inlet Size : 4 inches

Frequency : 50/60 Hz

Outlet Size : 3 inches

Voltage : 460V

Contact Now

Vertical Inline Pump Single Stage Vertical Centrifugal Pump Centrifugal Water Pump

Our Features

1. Compact, small size ,beautiful shape, and the area covered is small because of its structure insallltion. lts center of gravity is coincide with the foot of pump, thereby enhancing the operation stability and the operation life of the pump.

2. Vertical pump outlet and inlet is of the same diameter and at the same center line. The pump is easy to install, no need to change pipeline, can be installed directly to any part of the pipeline as like valve. Rain cover on the motor can be also placed outdoors.

3. Motor and pump is coaxial , simplifying the intermediate structure and increasing the smooth running of the impeller with excellent static and dynamic balance. Run in small vibration, low noise, therefore extending bearing life and improving the use of the environment.

4. Reliable sealed with wear-resistant material such as hard alloy and silicon carbide for mechanical seals, not only solve the pump packing seal leakage problem but increase service life.

5, Easy maintenance, Needless to remove pipe, only to remove the connection of the frame. And remove the motor and transmission components for repair and maintenance.

6, Its unique structure and elaborate design not only reduce the pumping station area, improve the space but also greatly reduce infrastructure investment.

Working Temp	20~120 Degree
Head	8~200 m
Power	0.18~200 kw
Speed	2800 r/min
Type	Centrifugal Pump
Capacity Q	1.5~30 L/s

1.Electric pump: kinds of end suction pump, split case pump, multistage pump.

made of cast iron, stainless steel. Impeller can be bronze.

5.5-710 kw 0.3-1.2 mpa 10-420 l/s (150-6600GPM)

2.Diesel pump: Flow is the same with electric pump. It connects the pump set with

High elastic coupling or universal joint. It also includes water tank,

oil tank, fans, control screen etc.

7.0-810 kw 0.3-1.2 mpa 10-420 l/s (150-6600GPM)

3.Jockey pump: horizontal or vertical, small flow,

head is higher than electric or diesel pump

4.Control panel: control the pumps automatically with overload, overcurrent protection

5.Accessories: check valve, gate valve, pressure tank (0.6mpa, 1.0mpa, 1.6mpa)

Pressure gauge, pressure sensors, import and export common pipe,

soft joints, flanges and common base.

Single Stage Centrifugal Water Pump Vertical Inline Pump 220V-380V

Product Paramenters
